RAPID® Hardwood WH
Approved for hardwood and BauBuche without pre-drilling
Washer head
- Highest permissible head pull-through values for sturdy joints pulled tightly together
- No washers required, which makes processing faster
Ø 8.0 x 160 mm
Minimised effort
- Minimised effort
- The patented friction part greatly reduces screw-in resistance
- Less effort required to screw in
- Faster screwing processes
- Suitable for cordless screwdrivers
Low splitting, high pull-out values
- Also suitable for coniferous timber
- 3-4 times higher values for hardwood, compared to coniferous timber
Patented tip – no pre-drilling necessary
- Bites rapidly even with oblique and cross grained wood screw connections
- Minimised splitting
- No pre-drilling in hardwoods and LVL beech (for lengths up to and including 400 mm; pre-drilling permitted for longer lengths)
Surface: BlueWin 700+
- Thick-film passivation, yellow
- Cr[VI] free
- Anti-friction coating
Other coatings or production in stainless steel possible on request.
Features
The RAPID® Hardwood is the first screw ETA-approved for all hard woods without pre-drilling, both for screwing in side and end timber (90° to 0°) and for screw fittings in the narrow edge of laminated veneer beech lumber.
The unique RAPID® Hardwood makes full loads possible regardless of whether the timber was pre-drilled. However, if you pre-drill with ø max. 6.5 mm screws, the RAPID® Hardwood’s screw-in torque will be reduced by 2/3 and the screw distances will be much smaller.
- Saves time by eliminating pre-drilling
- ETA approval
- Tensile capacity comparable to a conventional 10 mm wood construction screw
