RAPID® Hardwood WH

Approved for hardwood and BauBuche without pre-drilling

Washer head

  • Highest permissible head pull-through values for sturdy joints pulled tightly together
  • No washers required, which makes processing faster

Ø 8.0 x 160 mm

Minimised effort

  • Minimised effort
  • The patented friction part greatly reduces screw-in resistance
  • Less effort required to screw in
  • Faster screwing processes
  • Suitable for cordless screwdrivers

Low splitting, high pull-out values

  • Also suitable for coniferous timber
  • 3-4 times higher values for hardwood, compared to coniferous timber

Patented tip – no pre-drilling necessary

  • Bites rapidly even with oblique and cross grained wood screw connections
  • Minimised splitting
  • No pre-drilling in hardwoods and LVL beech (for lengths up to and including 400 mm; pre-drilling permitted for longer lengths)

Surface: BlueWin 700+

  • Thick-film passivation, yellow
  • Cr[VI] free
  • Anti-friction coating

Other coatings or production in stainless steel possible on request.

Features

The RAPID® Hardwood is the first screw ETA-approved for all hard woods without pre-drilling, both for screwing in side and end timber (90° to 0°) and for screw fittings in the narrow edge of laminated veneer beech lumber.
The unique RAPID® Hardwood makes full loads possible regardless of whether the timber was pre-drilled. However, if you pre-drill with ø max. 6.5 mm screws, the RAPID® Hardwood’s screw-in torque will be reduced by 2/3 and the screw distances will be much smaller.

  • Saves time by eliminating pre-drilling
  • ETA approval
  • Tensile capacity comparable to a conventional 10 mm wood construction screw
