RAPID® Hardwood CS
Approved for hardwood and BauBuche without pre-drilling
90° countersunk head
Ø 8.0 x 80 mm
Ø 8.0 x 100 mm
Ø 8.0 x 120 mm
Ø 8.0 x 160 mm
Ø 8.0 x 200 mm
Ø 8.0 x 240 mm
Ø 8.0 x 280 mm
Ø 8.0 x 320 mm
Ø 8.0 x 440 mm
90° countersunk head
- Countersinks fully into the wood and fits well in steel bores
- Milling pockets reduce tearing and splitting in the wood
Minimised effort
- The patented friction part greatly reduces screw-in resistance
- Less effort required to screw in
- Faster screwing processes
- Suitable for cordless screwdrivers
Low splitting, high pull-out values
- Also suitable for coniferous timber
- 3-4 times higher values for hardwood, compared to coniferous timber
Patentierte Spitze – Kein Vorbohren notwendig
- Rascher Anbiss auch bei Schräg- und Hirnholzverschraubungen
- Minimierte Spaltwirkung
- Kein Vorbohren in Harthölzern und FSH-Buche (bei Längen bis 400 mm, darüber mit Vorbohren zugelassen)
Surface
BlueWin 700+
- Thick-film passivation, yellow
- Cr[VI] free
- Anti-friction coating
Other coatings or production in stainless steel possible on request.
Features
The RAPID® Hardwood is the first screw ETA-approved for all hard woods without pre-drilling, both for screwing in side and end timber (90° to 0°) and for screw fittings in the narrow edge of laminated veneer beech lumber.
The unique RAPID® Hardwood makes full loads possible regardless of whether the timber was pre-drilled. However, if you pre-drill with ø max. 6.5 mm screws, the RAPID® Hardwood’s screw-in torque will be reduced by 2/3 and the screw distances will be much smaller.
- Saves time by eliminating pre-drilling
- ETA approval
- Tensile capacity comparable to a conventional 10 mm wood construction screw
