RAPID® Top-2-Roof

For on-roof insulation systems

Ø 8.0 x 240 mm
Ø 8.0 x 260 mm
Ø 8.0 x 280 mm
Ø 8.0 x 300 mm
Ø 8.0 x 320 mm
Ø 8.0 x 360 mm
Ø 8.0 x 400 mm
Ø 8.0 x 450 mm
Ø 8.0 x 480 mm
Ø 8.0 x 520 mm

Features

Cylinder head

  • Reduced splitting so that wood surface does not splinter
  • Improved force transfer thanks to deeper drive

Fast screwing processes – Lower screw-in resistance

  • Coarse thread rolled out to the tip
  • Low screw-in torque
  • The friction part reduces the screw-in resistance by reaming the wood around the shaft

No pre-drilling necessary

  • Patented follower thread tip
  • Ensures that screw bites quickly with low splitting

Surface: BlueWin

  • Passivation, blue
  • Cr[VI] free
  • Anti-friction coating

Other coatings or production in stainless steel possible on request.

Application

  • Approved for hard and soft insulation
  • Optimal for non-pressure-resistant (soft) insulation
  • Especially for on-roof insulation: Absorbs thrust and compression forces
  • The absorption of compression forces causes the insulation not to be pressed into the substrate nearly as much, which improves insulating capacit
  • The second threaded part underneath the screw head keeps the counter batten optimally fixed in place
Roof and external wall insulation
  • Counter batten verification incl. screwing
  • Gabled and monopitch roofs
  • Wall insulation 90°

Dimensioning software

  • Easy and intuitive to operate - the EXCEL table calculation program does not require any special software knowledge
  • Takes much less time to calculate
  • Screw types and pre-defined insulations can be selected or you can customise by adding your own insulation
  • The software takes national regulations into account and is available in German, English, French and Italian

Request now
